Double Action Deep Draw Press

Double Action Deep Draw Press (100 Ton)

Double Action Deep Draw Press (200 Ton)

Double Action Deep Draw Press (300 Ton)

Double Action Deep Draw Press

Specifications:

Our hydraulic deep draw press are highly rigid, compact, space saving four-pillar type in design. Hydraulic deep drawing press are equipped with PLC, L.V.D.T depth control, photo sensor electronic safety guard, auto ejector. They are specially designed for uniform pressure on blank holder to avoid wrinkles during the process which improves the quality and productivity rate of products. Hydraulic deep draw press is suitable for manufacturing stainless steel utensils and other automobile draw components with high degree of finish, productivity and speed.

TECHNICAL PARAMETERS

MODEL NO.	CAP. TON	Main cyl. cap. (mm)	Blank holder cap (mm)	bolster size (mm)	day-light gap	blank holder stroke	maincyl. stroke	motor h.p.	EJECTOR CYL. CAP. (Tons)
RDD 100	100	50	50	700 X 700	500	300	500	7.5 X 1	10
RDD 150	150	75	75	900 X 700	600	300	500	7.5 X 1	10
RDD 250	200	100	100	900 X 900	600	300	600	10 X 1	15
RDD 400	300	150	150	1200 X 1000	750	400	700	20 X 1	20
RDD 500	400	200	200	1200 X 1200	800	450	750	20 X 1	20
RDD 500	500	250	250	1500 X 1200	800	450	750	25 X 1	20
RDD 600	600	300	300	1500 X 1800	900	450	850	30 X 2	25
RDD 800	800	400	400	1800 X 1500	1000	500	900	40 X 2	25
RDD 1000	1000	500	500	2000 X 1800	1200	600	1100	50 X 2	25

Note:

» » Hydraulic Deep Draw Press can be designed Pillar / Gate / Frame Type
» High Capacity press will be designed column type preferably.
» Hydraulic Deep Drawing Press can be provided with speed as per customer requirement.
» The motor H.P. can be changed as per the speed provided
» Click here to Request a Quotation for Hydraulic Press over & above the specified capacity.
* Specially Designed for S.S. Kitchen Sink Manufacturing
